AC Input
Voltage: 3Ø3W+G; 380VAC ± 15% (Option 200VAC/208VAC/480VAC)
Frequency: 47-63Hz
Power Factor: ≧ 90% at maximum power
DC Output
Voltage: 1600V
Current(100kW): 63A
Line Regulation: ≦ 0.1%
Load Regulation: ≦ 0.08%
Transient Response*2: ≦ 10-20ms
Measurement*3:
Voltage Accuracy: 0.5% F.S
Voltage Resolution: 0.1V
Current Accuracy: 0.5% F.S.
Current Resolution: 0.1A
Protection:
Type : Vin OVP, Vin UVP, OVP, OTP
OVP Range: 5 - 115% from front panel
OCP Range: 5 - 115% from front panel
General:
Efficiency: ≧ 90% at maximum power
Interfaces: Standard : RS-485 Option : GPIB; RS-232; Analog, USB
Operating Temperature: 0°C-40°C
Storage Temperature: -20°C-70°C;
Humidity: 0-90%(Non condensing)
Isolation: Input to enclosure: 2000VAC
Dimension(H×W×D)*4:
- 200VAC/ 208VAC input: 1902x600x800mm/ 74.8x23.7x31.5 inch
- 480 VAC Input: 1837x600x800mm/ 72.3x23.7x31.5inch
- 380 VAC Input: 1492x600x800mm/ 58.7x23.7x31.5inch
Weight*4:
- 380V Input: approx 298kg/ 656.9 lbs
- 200V/ 208V/ 480V Input: approx 570kg/ 1256.6 lbs
*2 Recover to ±0.1% of regulated output with a 50% to 100% or 100% to 50% step load change
*3 The specifications are tested at ambient temperature of 25°C ± 5°C
*4 Including wheels and weight tolerance is within ±10kg
* Above specifications are for output voltage over 1% F.S and all specifications are subject to change without notice.
