Output Power : 15kW
INPUT:
Input Voltage: A: 3Ø4W+G 340-460 Vac / B: 3Ø3W+G 187-264 Vac
Input Current: A: 3ØY 30A / B: 3ØΔ 52A
Input Frequency: 47-63 Hz
Power Factor: ≥0.99
OUTPUT:
Voltage: 0-80V
Current: 0-510A
Voltage Ripple (RMS)*1: ≤0.15% F.S.
Voltage Ripple (peak to peak)*1: ≤2% F.S.
Voltage Line Regulation: ≤0.1% F.S.
Voltage Load Regulation*2: ≤0.1% F.S.
Current Ripple (RMS): ≤0.05% F.S.
Current Line Regulation: ≤0.05% F.S.
Current Load Regulation: ≤0.15% F.S.
Slew Rate – Rise Time: ≤15 ms
Slew Rate – Fall Time (Full Load): ≤8 ms
Fall Time (No Load): ≤ 3s
Transient Response: ≤ 5ms
Programming & Measurement:
Voltage Programming Accuracy: ≤ 0.08% F.S. + 0.01V
Voltage Measurement Accuracy: ≤ 0.08% F.S. + 0.01V
Voltage Resolution: 10 mV
Current Programming Accuracy: ≤ 0.2% F.S. + 0.1A
Current Measurement Accuracy: ≤ 0.2% F.S. + 0.1A
Current Resolution: 0.1 A
Power Programming Accuracy: ≤ 0.3% F.S.
Power Measurement Accuracy: ≤ 0.3% F.S.
Power Resolution: 0.01 kW
General Specs:
Efficiency*5: ≥ 90% at max. power
Interfaces: Standard: RS-232, RS-485, Ethernet, USB, Analog; Option: GPIB
Analog Input Control (V & I): 0–5V, 4–20mA, Accuracy: 1% F.S. (at output rated voltage & current ≥ 5%)
Analog Output Monitor (V & I): 0–5V, Accuracy: 2% F.S.
Remote sense compensation: ≤ 5V
Operating Temperature: 0°C ~ 40°C
Storage Temperature: −20°C ~ 70°C
Protections: OVP, OCP, OPP, OTP, Vin OV, Vin Unbalance, LDC OV
OVP Range: 0–110% F.S.
OCP Range: 0–110% F.S.
OPP Range: 0–110% F.S.
Dimension (H×W×D): 132 × 442 × 731.5 mm / 5.2 × 17.4 × 28.8 inch
Weight*6: approx. 34.4 kg / 76 lbs
