Output Power: 5kW
INPUT
Input Voltage: 1Ø 2W+G 187-264 VAC; 3Ø3W+G 187-264 VAC; 3Ø4W+G 340-480 VAC
Input Current: 1Ø : 60A; 3ØΔ: 35A; 3ØY : 19A
Input Frequency: 47 Hz - 63 Hz
Power Factor: ≧ 0.99 at max. power
OUTPUT
Voltage:0~80V
Current: 0~170A
Voltage Ripple (RMS): ≦ 0.08% F.S.
Voltage Ripple (peak to peak): ≦ 0.8% F.S.
Voltage Line Regulation: ≦ 0.03% F.S.
Voltage Load Regulation*1: ≦ 0.05% F.S.
Current Ripple (RMS): ≦ 0.25% F.S.
Current Line Regulation: ≦ 0.05% F.S. +50mA
Current Load Regulation: ≦ 0.25% F.S.
Slew Rate*3: Rise Time: ≦ 60ms; Fall Time (Full Load): ≦ 45ms; Fall time (No Load): ≦ 3s
Transient Response*2: ≦ 5ms
Programming & Measurement
Voltage Programming Accuracy: ≦ 0.08% F.S. +100mV
Voltage Measurement Accuracy: ≦ 0.08% F.S. +100mV
Voltage Resolution: 100mV
Current Programming Accuracy: ≦ 0.3% F.S. +60mA
Current Measurement Accuracy: ≦ 0.3% F.S. +60mA
Current Resolution: 10mA
Power Programming Accuracy: ≦ 0.4% F.S.
Power Measurement Accuracy: ≦ 0.4% F.S.
Power Resolution: 0.01kW
General Specs.
Efficiency: ≧ 90% at max. power
Interfaces: Standard: RS-485/RS-232 (Modbus) & Analog; Option : Ethernet/USB/RS-485/RS-232 (SCPI) or GPIB
Remote sense compensation: ≦ 5V
Operating Temperature: 0° C ~ 40° C
Storage Temperature: -20° C ~ 70° C
Protections: OVP、OCP、OPP、OTP、Vin OV、Vin Unbalance 、LDC OV
OVP Range: 0~110% F.S.
OCP Range: 0~110% F.S.
OPP Range: 0~110% F.S.
Dimension (HxWxD): 132 x 442 x 692 mm / 5.2 x 17.4 x 27.2 inch
Weight: approx. 26.5kg / 58.42 lbs
*1. Load changes from 0% to 100% under nominal AC input.
*2. Under nominal AC input, recovers to ±1% of full-scale output voltage for a 50% to 100% or 100% to 50% load change.
*3. Measured from 10% to 90% of the output voltage change - resistive load, typical.
** Above specifications are under output voltage over 1% F.S.
* All specifications are subject to change without notice.
