Capacity Range: (250–5600) kPa
Measurement Units: kPa, kgf/cm², Lb/cm²
Resolution: 0.01 kPa
Accuracy (Indication Error): Better than ±0.5% FS
Indication Variability: Better than 0.5%
Clamp Ring Diameter: Compliant with GB/T 1539
Oil Pressure Speed: (170±15) ml/min
Film Resistance Convex Height: 10 mm / 18 mm
Membrane Resistance: (170–220) kPa / (250–350) kPa
Pressure Plate Diameter (Upper): Φ 31.50 mm ± 0.05
Pressure Plate Diameter (Lower): Φ 31.50 mm ± 0.05
Test System Tightness: Pressure drop <10% Pmax within 1 minute
Specimen Holding Force: 400–1200 kPa (according to GB/T1539-2007)
Instrument Parameters
Units: kPa, psi (Lbf/in²), kgf/cm², with unit switching function
Printings: High-speed thermal printer (serial number, max/min, peak, average values, etc.)
Weight: Around 52 kg
Control: Color touch screen with Chinese & English display (with curve display)
Hydraulic Oil: Silicone
Equipped Air Compressor Exhaust Volume: (0.02–0.3) m³/min
Rated Pressure: (0.6–0.7) MPa
Dimension: 370 × 400 × 550 mm
Power: AC220V 50Hz, 120 W
Instrument Gas Source: Customer-prepared air compressor (optional)
Standard Delivery:
1 wrench
2 bottles of special silicone oil
10 calibration sheets
3 rubber films
1 third-party measurement report
