Voltage generators
Setting range
4‐phase ac(L‐N): 4×0~300V
1‐phase ac(L‐L): 1×0~600V
dc (L‐N): 4×±0~300V
dc (L‐L): 1×±0~600V
Power
4‐phase ac(L‐N): 4×75VA typ., at 300V; 4×50VA guar., at 300V
3‐phase ac(L‐N): 3×100VA typ., at 300V; 3×85VA guar., at 300V
1‐phase ac(L‐L): 1× 200VA typ., at 600V; 1× 170VA guar., at 600V
dc (L‐N): 4×100W at 300 V
Accuracy error:
< 0.08 % rd.+0.02 % rg. guar., at 0~300 V
< 0.02 % rd.+0.01 % rg. typ., at 0~300 V
Ranges: 300V
Resolution: 10mV
Distortion: < 0.05 % typ., (< 0.1 % guar.)
Current generators
Setting range
6‐phase ac(L‐N): 6×0~15A
3‐phase ac(2L‐N): 3×0~30A
1‐phase ac(3L‐3L): 1×0~30A (10A/phase)
1‐phase ac(6L‐N): 1×0~90A
dc (L‐N): 6×±0~10A
dc (6L‐N): 1×±0~60A
Power
6‐phase ac(L‐N): 6×105VA at 15A
3‐phase ac(2L‐N): 3×210VA at 30A
1‐phase ac(3L‐3L): 1×420VA at 30A
dc(L‐N): 6×100W at 10A
dc(6L‐N): 600W at 60A
Max compliance voltage(L‐N)(L‐L): 10Vpk/20Vpk
Accuracy error:
< 0.08 % rd.+0.02 % rg. guar., at 0~15A
< 0.02 % rd.+0.01 % rg. typ., at 0~15A
Ranges: 15A or 30A
Resolution: 1mA
Distortion: < 0.05 % typ.,(< 0.1 % guar.)
Phase
Angle range: ‐360°~+360°
Accuracy: <0.05° typ., <0.1° guar.at 50/60Hz
Resolution: ±0.001°
Operation temperature: 0~+50°C
Storage temperature: ‐25~+70°C
Relative humidity: 5~95% non‐condensing
Weight: 16kg
Dimensions (W x H x D): 390mm ×287mm×214mm
