Track resistance
Ranges Ω: 200mΩ, 2Ω, 200Ω, 20kΩ
Accuracy: ±6% in 200mΩ ±5% in 20kΩ, 2Ω ±4% in 200Ω
Ω range: High sensitivity uncalibrated, approximately 40mΩ full scale
Probe voltage: 60mV maximum
Probe protection: ±30V
Indication: Tone and meter on all ranges
Track Current
Ranges: 200mA, 2A, Trace
Accuracy: 200mA, 2A, ±15%
Trace: Reading proportional to current when UNCALIBRATED illuminates. Reading proportional to detected magnetic field strength
Probe voltage: maximum in 200mA, 2A
Probe protection: ±30V
Indication: Tone and meter on all ranges
Track voltage
Ranges: 2mV, 20mV, 20V
Accuracy: ±4% ±15µV
Input resistance: 120Ω in 2mV, 20mV 1MΩ in 20V
Probe protection: ±30V
Indication: Tone and meter on all ranges
Plane shorts
Indication: Tone, digital display and LED fault direction arrows
Sensitivity: Adjustable to compensate for differing plane resistance
Drive source
Output voltage: 0 to 550mV, adjustable. AC in TRACE, DC in all other modes. Protected to ±30V
Plane stimulus
Output voltage: 550mV maximum
Power req:
230V±10% or 115V±10% @ 50/60Hz, 25VA
Accessories (Description / Part Number)
Standard:
Needle probes: ACC152
Current trace/drive source probe: ACC114
Plane probe: ACC113
Plane stimulus leads: ACC134
Lightweight headphones: EPM115
Operator manual: MAN129
Optional:
Graphical repair software: GRS25
Service manual: MAN130
Bare board stimulus leads: ACC231
Approvals:
Conforms to applicable European Directives and is CE marked
Polar Instruments Ltd is certified to ISO 9001
