- DC input voltage:DC24V
- DC voltage standard: 26.8V
- AC voltage standard: AC223V
- Output power continuous: 10000W
- Surge rating: 20kw
- Effi ciency et rated power: 91%
- No load current: no fan: 1.26A
on fan: 2.9A
- Low battery shut down: 20.0V
- Low battery return on power: 22.4V
- High battery shut down: 31.7V
- High battery return on power: 30V
- Equency[50/60] selection: 60HZ
- Regulation: 1000W/222Vac
- Over temperature protection: -25℃ ~ +74℃
- Over temperature power on: 58℃
- Output wave form: Pure sine wave
- Cooling fan [auto fan]: Fan on temperature 40℃ (±0.5℃)
- Insulation transformer: 2KV ~ 2.5KV
- Over load protection:
Input senser: 100A
Input fuse: 40A(12EA)
Output sensor: 50A(Sensor)
Output circuit breaker: 50AH(DCP-PR)
16A*2(SS-001)
AC outlet/terminal: 2P Outlet 16A / 1P-20A(EU-US)
3P-60A Terminal
- FCC (EMC) / AC120V: FCC part 15 sub part B class A
- KC (EMC) / AC220V: MSP-REMpnk-DK2410K
- Dimensions [W×H×D(mm)]: 225×89×750 mm
- Weight: 17.5kg
