Frequency range: 300 kHz to 8.5 GHz
Frequency setting resolution: 10 Hz
Frequency accuracy: 10 ppm max With ambient of 23 ±3 °C
Frequency temperature stability: ±0.5 ppm/ºC max Over the range +15 °C to +35 °C
Harmonics: –20 dBc max With test power set to < –3 dBm
Non-harmonic spurious: –40 dBc typical
Phase noise (10 kHz offset):
0.3 MHz to 1 GHz: –90 dBc/Hz
1 GHz to 4 GHz: –80 dBc/Hz
> 4 GHz: –76 dBc/Hz
Test signal power
≤ 6 GHz: +10 dBm ~ –20 dBm
> 6 GHz: + 6 dBm ~ –20 dBm
Power setting resolution: 0.1 dB
Power setting accuracy: ±1.5 dB
Reference input frequency: 10 MHz ±6 ppm
Reference input level: 0 ±3 dBm
Reference output level: 0 ±3 dBm
Miscellaneous:
Controlling PC data interface: USB 2.0
Support for third party test software: Dynamic Link Library (DLL) as part of user interface software
External dimensions (mm): 286 x 174 x 61 (L x W x H) excluding connectors
Weight: 1.9 kg
Temperature range (operating): +15 °C to +35 °C
Temperature range (storage): –20 °C to +50 °C
Humidity: 80% max, non-condensing
Vibration (storage): 0.5 g, 5 Hz to 300 Hz
Power source and current: +12 to +15 V DC, 22 W
Power source connector: 5.5 mm diameter hole, 2.1 mm diameter centre contact pin.
Centre pin is positive.
Host PC requirements Microsoft Windows 7, 8 or 10
2 GB RAM or more
