Input channels: 4
Bandwidth: (–3dB) 300 MHz
Rise time: < 1.3 ns
Bandwidth limit: 20 MHz, có thể chọn
Vertical resolution: 8 bits fixed
Input sensitivity: 2 mV/div ~ 4 V/div (10 vertical divisions)
Enhanced vertical resolution (software): Up to 4 extra bits beyond ADC resolution
Maximum sampling rate (real time, 8-bit mode):
Up to 2 total analog channels and MSO pods 5 GS/s
Up to 4 total analog channels and MSO pods 2.5 GS/s
Triggering
Trigger modes: None, auto, repeat, single, rapid (segmented memory)
Advanced trigger types (digital inputs): With optional MSO pods: Edge, pulse width, dropout, interval, pattern, logic (mixed signal)
Automatic measurements
Scope mode: AC RMS, true RMS, frequency, cycle time, duty cycle, DC average, falling rate, rising rate, low pulse width, high pulse width, fall time,
rise time, minimum, maximum, peak to peak
Spectrum mode: Frequency at peak, amplitude at peak, average amplitude at peak, total power, THD %, THD dB, THD+N, SFDR, SINAD, SNR, IMD
Statistics: Minimum, maximum, average, standard deviation
PC connector type: USB Type B
Power requirement: 12 V DC from supplied PS016 PSU. Up to 7 A including powered accessories.
Dimensions: 245 x 192 x 61.5 mm
Weight 2.2 kg
