Nominal division ratio: 20:1
Bandwidth (–3 dB): > 4 GHz
Max. usable data rate (fundamental): 8 Gb/s
Max. usable data rate (3rd harmonic): 2.6 Gb/s
Max. usable data rate (5th harmonic): 1.6 Gb/s
Transition time: < 87.5 ps
Probe tip impedance (nominal): 960 Ω
Probe tip capacitance (typical): 0.3 pF
Probe tip capacitance (maximum): 0.4 pF
Accuracy for line Z0 = 40 Ω to 60 Ω: < ±0.13 dB (±1.6%)
Accuracy for line Z0 = 0 Ω to 100 Ω: < ±0.25 dB (±2.9%)
Nominal error for line Z0 = 75 Ω: < –0.17 dB (–1.9%)
Continuous voltage: 14 V AC RMS
DC blocking voltage (max.): 50 V DC
Peak voltage: < 150 V
Environment:
Operating temperature range: 0 to 50°C
Storage temperature range: –20 to 70°C
Temperature range for stated specifications: 15 to 40°C
Operating humidity range: 5% to 80% RH non-condensing
Storage humidity range: 5% to 95% RH non-condensing
Altitude range: up to 2000 m
Pollution degree: 2
