LIN interface for the USB connection (Full-Speed mode, compatible with USB 1.1, USB 2.0, and USB 3.0)
LIN connection (ISO 17987)
Compliant with all LIN specifications (up to version 2.2)
Bit rates from 1 kbit/s up to 20 kbit/s
Can be used as a LIN master or slave (1 ms master task resolution)
Automatic bit rate, frame length, and checksum type recognition
Autonomous scheduler with support for unconditional, event, and sporadic frames
LIN bus connection via D-Sub, 9-pin
LIN connection short-circuit-proof against transceiver supply and ground
NXP LIN transceiver TJA1028T or TI LIN transceiver TLIN1028D
Galvanic isolation on the LIN connection up to 500 V
Indicator LED for interface status
Voltage supply 5 V DC via USB port
Transceiver supply 6 to 28 V DC via D-Sub, pin 9
Extended operating temperature range from -40 to +85 °C (-40 to +185 °F)
