PCE WL 2-ICA Air Velocity Meter

Specifications

Inputs:2 x digital inputs; 1 x analogue input; 1 x NTC input for external temperature sensors

Interface:RS-232

Sampling interval:1 min or 10 min

Memory:microSD card (FAT32), max. 2 GB

Data format:CSV file, ASCII format

Recorded parameters:average values, min/max values and standard deviations (with date and time stamp)

Power supply:2 x 1.5 V type C batteries

Battey life:up to 1 year (with 1 min sampling interval); up to 3 years (with 10 min sampling interval)

Housing:robust plastic housing

Protection class:IP65

Dimensions:160 x 80 x 55 mm

Weight:450 g

Wind energy sensor

Wind energy- velocity sensor

Measuring range:1 ... 40 m/s

Sensor:2 reed contacts (zero potential)

Output:impulses zero potential

Resolution:2.3 Hz/ms-1

Maximum applied load:10 VA, 0.5 A, 42 VDC

Wind energy wind direction sensor

Measuring range:2.5 ... 357.5 º

Sensor:0 ... 1 KΩ

Neutral position:5 º open to north

Wind energy sensor general technical data

Dimensions:418 x 30 mm

Mast support:31 x 26 mm

Protection standard:IP54

Weight:1 kg

Delivery contents

1 x PCE-WL 2 Air Velocity Meter

1 x wind speed sensor

1 x wind direction sensor

1 x 512 MB SD memory card

2 x battery

1 x user manual

1 x ISO Calibration Certificate
