Temperature range: -10 to 250°C
Sensor: uncooled focal plane array
Measurement points / Resolution: 160 x 120 pixels (19,200 points)
Accuracy: ±2°C or ±2%
Display resolution: 192 x 192 pixels
Lens: (FOV) 20° x 15°
Focus: manual
Measurement distance: 30cm to infinity
Measurement functions: two moveable points, measures difference
Temperature resolution: 0.15ºC
Image frequency: 7.5 Hz
Spectral range: 8 to 14µm
Emissivity: 0.2 to 1.0 (adjustable in steps of 0.01)
Memory: MMC or SD memory card
Port: USB type B
Display: 3.5" LCD, with back lighting and four adjustable colour palettes: rainbow, iron bow, hc rainbow and grey scale
Temperature units: ºC, ºF or K
Laser pointer: class II 1mW / 635nm
Operating temperature: -15 to 45ºC
Storage temperature: -20 to 70ºC
Air humidity: 10 to 90% r.h. without condensation
Power: ion-litium rechargeable
Operating: time 4 to 6 hours
Enclosure: plastic Tripod screw 1/4"
Weight 750gr
Dimensions: 230 x 120 x 110mm
Manufacturer: PCE - ENGLISH
Origin: UK
Discontinued
