PCE IR 56 Infrared Thermometer (-20~1000°C;±1％)

Specification

Measurement range (selectable):-20... 1000 °C / -4 ... 1832°F

Accuracy:± 1% of measured value

Emissivity:0.2 ... 1.0 adjustable

Distance-to-target ratio:20:1

Spectral range:8 ... 14 µm

Power supply:24V DC

Impedance:900 Ohm

Interface (selectable):Modbus RTU

Storage rate:1/s ... 1/Tag

Micro SD card:Max. 2 GB (not included in delivery)

Data format:CSV

Dimensions display:96 x 64 x 36 mm / 3.8 x 2.5 x 1.4 in

Dimensions temperature sensor: Ø18 x 45 mm / .7 x 1.8 in

M16

Cable length:1 m / 3.3 ft

Weight:280 g / < 1 lb

Protection class:IP65

Ambient temperature: 0 ... 120°C / 32 ... 248°F

Ambient relative humidity:Max. 95% RH

Delivery contents

1 x Infrared thermometer PCE-IR 56 incl. selected sensors

1 x Sensor hub (starting from 2 sensors)

1 x User manual
