Maximum measurement load |
5.000 N / 500 kg |
|
Resolution |
1 N / 100 g |
|
Dynamometric cell cable length |
approx. 3 m |
|
Measurement uncertainty |
±0,05 % of the measurement value |
|
Gravitation map |
manual setting by means of a GPS |
|
Measuring units |
N, g, lb, oz, kg |
|
Calibration |
with F2 calibration weights |
|
maximum overload |
±20 % of the measurement range |
|
Measurement rate |
adjustable 10 values/s or 40 values/s |
|
Measurement function |
Traction and compression measurement / PEAK function (max, min, Hold) / measurement of limit values / real time measurements by means fo the software |
|
Display |
61 x 34 graphic display / simultaneous indication of relevant values such as date, time and current measurement value / automatic reverse display / setting of backlight, etc... |
|
Menu |
multilingual: German / English / Spanish |
|
Internal memory |
8 memory positions with 800 respective measurements |
|
Record |
manual - pressing one button |
|
Interface |
RS-232, 9 poles |
|
Printer connection |
through the RS-232 interface |
|
Software and data cable |
with software for the control and valuation l |
|
Operating conditions |
-10 ºC ... +40 ºC |
|
Power supply |
internal NiMH accumulator |
|
Accumulator duration |
approx. 20 h (without backlight, approx. 45) |
|
Dimensions |
210 x 110 x 40 mm |
|
Weight |
550 g (without the dynamometric cell) |
Manufacturer: PCE - UK
Warranty: 12 months
Discontinued
