Measuring functions
mA DC Current
Range:
4 … 20 mA
0 … 20 mA
24 mA
Resolution:
1 µA
1 µA
1 µA
Accuracy:
±0,015 % +2 µA of the measuring value
±0,015 % +2,6 µA of the measuring value
±0,015 % +2 µA of the measuring value
Temperature coefficient: <20 ppm="" c="" de="" 0="" 18="" c="" y="" de="" 28="" 50="" c="" p="">
Possible circuit feeder: 24 V ±10 %
Input resistance (Rin): <30
HART compatibility: R = 250 Ω
Common Mode Suppression: 120 dB a 50 y 60 Hz
V DC Voltage
Range
0 ... 10 V
25 V
50 V
Resolution
1 mV
1 mV
1 mV
Accuracy
±0,015 % + 2 mV of the measuring value
±0,015 % + 2 mV of the measuring value
±0,015 % + 4 mV of the measuring value
Temperature coefficient: <15 ppm="" c="" de="" 0="" 18="" c="" y="" de="" 28="" 50="" c="" p="">
Series mode rejection: >60 dB a 50 y 60 Hz
Common mode rejection: >120 dB a 50 y 60 Hz
Function generator
mA DC Current
Range:
4 … 20 mA
0 … 20 mA
24 mA
Resolution:
1 µA
1 µA
1 µA
Accuracy:
±0,015 % +2 µA of the measuring value
±0,015 % +2,6 µA of the measuring value
±0,015 % +2 µA of the measuring value
Temperature coefficient: <20 ppm="" c="" de="" 0="" 18="" c="" y="" de="" 28="" 50="" c="" p="">
Attack: <500 s="" 0="" 20="" ma="" con="" una="" carga="" de="" 20="" p="">
Low frequency noise: <1 a="" con="" f="" 100="" hz="" p="">
V DC Voltage
Range:
0 ... 10 V
15 V
Resolution:
1 mV
1 mV
Accuracy
±0,015 % + 2 mV of the measuring value
±0,015 % + 2 mV of the measuring value
(Iout max = 10 mA (a 10 V))
(Iout max = 8 mA (a 15 V))
Temperature coefficient: <15 ppm="" c="" de="" 0="" 18="" c="" y="" de="" 28="" 50="" c="" p="">
Attack: <1 ms="" 0="" 15="" v="" con="" una="" carga="" de="" 1="" m="" p="">
Internal resistance: 1 Ω
Low frequency noise: <1 mv="" con="" f="" 100="" hz="" p="">
Continuity function
Range: Continuity
Resolution: open / close
(it is considered as closed if Z=[0 ... 1 kΩ] and open if Z=[1 kΩ ... ∞ ]
General properties
Display: 160 x 160 graphic display
Operating temperatura range: 0 ... +50 ºC
Operating humidity range: <85 h="" r="" p="">
Storage temperature: -10 ... +60 ºC
Storage humidity: <85 h="" r="" p="">
Power: 4 x AA batteries or 1,7 Ah accumulator
Operating time:
U and I measurement (>40 h)
mA / 24 V simulation (>10 h)
Standby mode >95 days
Battery indication: yes
Dimensions : 157 x 85 x 45 mm
Weight: approx. 300 g
Manufacturer: PCE-UK
Warranty: 12 months
Discontinued
