PCE PTR 200 Force Gauge (0~200 N; 0,1 N)

Measuring range: 0 ... 200 N / 0 ... 45 lbs

Resolution: 0.1 N / 0.02 lbs

Pressure calibration: 1 Mpa

Load cell: Integrated load cell with M6 connection

Measuring range: 1 ... 100% of the full scale

Measurement accuracy: ± 0.5%

Units: n, kg, lb

Display: LCD

Operating temperature: 10 ... 30°C / 50 ... 86°F

Relative humidity: 15 ... 80% relative humidity

Working conditions: The device must not be located near sources of vibration or corrosive substances

Weight: 1 kg / 2.2 lbs

Delivery Scope:

1 x Dynamometer (Penetrometer) PCE-PTR 200N

1 x Penetration tip Ø 6 mm

1 x Penetration tip Ø 8 mm

1 x Penetration tip Ø 11 mm

1 x Flathead adapter

1 x Hook adapter

1 x Ball head adapter

1 x Chisel head adapter

1 x Notch head adapter

1 x Extension rod (65 mm)

1 x USB cable

1 x Power plug

2 x Locking rings

1 x Equipment case

1 x Software

1 x User manual
