Fall Time: 45.7 ns
Rise Time: 73.1 ns
Technology: Si
Unit Weight: 297 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 34.3 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 168.8 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 37.7 ns
Typical Turn-Off Delay Time: 118.9 ns
Id - Continuous Drain Current: 19.7 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 180 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 4.7 V
