Standard specification
Spectral range: 200 - 440 nm ± 5 nm
Spectral bandwidth: 2 nm
Irradiance meas. range: 2 - 5000 mW/cm²
Dose measurement range: 1 mJ/cm² - 600 J/cm²
Resolution: 0.1 mW/cm² / 1 mWcm²
Calibration: traceable to PTB/NIST
Calibration: uncertainty typ. 5,0% - 9,5%
Cosine correction: Yes
Data storage rate: 100 Hz to 1 Hz, adjustable
Measurement time: 5 s to 8 min depeding on data storage rate
Sampling rate: 10 ms - 1000 ms
Display: graphical, 128 x 64 px
Dimensions: 160 x 100 x 14,4 mm³
Sensor position: at the rear side
Weight: ~ 375 g
Operation temperature: 10 - 70 °C briefly for up to 60s at 120°C ambient temperature
Batteries: 3 x CR2032
Memory: 50 measurements
Interface: USB
System requirements: Windows 10
DELIVERY
UVpad, PC-software, manufacturers certificate of calibration, USB cable and case
