Detector Type: InGaAs
Rise Time/Fall Time: <0.025 nsec
Spectral Range: 900-1700 nm
Active Area Diameter: 0.032 mm
Noise Equivalent Power: 20 pW/√Hz
Dimensions: 54 L x 34 W x 40 D (mm)
Detector Area: 0.00080 mm²
Responsivity at Peak Wavelength: 0.95 A/W
Responsivity (Irradiance) at Peak Wavelength: 0.19 x 10⁻³ V/(W/cm²)
Bias Voltage: 6 VDC
Bias Voltage Source: Batteries
Bandwidth: >15 GHz
Dark Current: <3 nA
Maximum Average Power Input: 10 mW
Mounting (Tapped Holes): 8-32 & M4
Output Connector: SMA
Accessory Threads: M20x1
Compliance: CE, UKCA, China RoHS
