Fall Time: 30 ns
Rise Time: 12 ns
Technology: Si
Unit Weight: 8.500 mg
Channel Mode: Enhancement
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 P-Channel
Qg - Gate Charge: 10.4 nC
Number of Channels: 2 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.4 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 39 ns
Id - Continuous Drain Current: 5.6 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 16 S
Rds On - Drain-Source Resistance: 50 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 500 mV
