Width: 2 mm
Height: 0.75 mm
Length: 2 mm
Fall Time: 9.2 ns
Rise Time: 9.2 ns
Technology: Si
Unit Weight: 28.840 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 6.5 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.5 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 4.8 ns
Typical Turn-Off Delay Time: 14.2 ns
Id - Continuous Drain Current: 3.7 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 4.5 S
Rds On - Drain-Source Resistance: 70 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 400 mV
