Width: 2 mm
Height: 0.75 mm
Length: 2 mm
Fall Time: 13.2 ns, 15 ns
Rise Time: 13.2 ns, 15 ns
Technology: Si
Unit Weight: 8.800 mg
Channel Mode: Enhancement
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 P-Channel
Qg - Gate Charge: 6.2 nC
Number of Channels: 2 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.5 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 5.2 ns, 5.5 ns
Typical Turn-Off Delay Time: 13.7 ns, 19.8 ns
Id - Continuous Drain Current: 3.3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 106 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1 V
