Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 6 mg
Qualification: AEC-Q101
Amplifier Type: Low Power Operational Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 150 mV/us
THD plus Noise: 0.04 %
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Ib - Input Bias Current: 1.5 nA
Operating Supply Current: 23 uA
Vcm - Common Mode Voltage: 1.6 V to 5.7 V
Ios - Input Offset Current: 1.1 nA
Output Current per Channel: 8.5 mA
Vos - Input Offset Voltage: 4 mV
GBP - Gain Bandwidth Product: 350 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 300 fA/sqrt Hz
en - Input Voltage Noise Density: 40 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 79 dB
PSRR - Power Supply Rejection Ratio: 90 dB
