Shutdown: No Shutdown
Output Type: Rail-to-Rail
Unit Weight: 173 mg
Qualification: AEC-Q100
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 2.4 V/us
THD plus Noise: 0.001 %
Number of Channels: 4 Channel
Supply Voltage - Max: 36 V, +/- 18 V
Supply Voltage - Min: 2.7 V, +/- 1.35 V
Ib - Input Bias Current: 1.5 nA
Operating Supply Current: 465 uA
Ios - Input Offset Current: 200 pA
Output Current per Channel: 65 mA
Vos - Input Offset Voltage: 1.3 mV
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 1.35 V
GBP - Gain Bandwidth Product: 3 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 90 fA/sqrt Hz
en - Input Voltage Noise Density: 20 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 145 dB
PSRR - Power Supply Rejection Ratio: 135 dB
