Width: 26.67 mm
Height: 8.51 mm
Length: 38.86 mm
Unit Weight: 13.835 g
REACH - SVHC: Details
Configuration: Single
Mounting Style: Through Hole
Transistor Polarity: NPN
Pd - Power Dissipation: 300 W
DC Current Gain hFE Max: 18000
Emitter- Base Voltage VEBO: 5 V
Collector- Base Voltage VCBO: 120 V
Continuous Collector Current: 50 A
Maximum DC Collector Current: 50 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 1000
Collector- Emitter Voltage VCEO Max: 120 V
