Computing System: 1024-Point FFT Calculation
Measurement RPM Range: 500 Hz Range: 3.75 Hz to 500 Hz, 2 kHz Range: 15 Hz to 2 kHz, 10 kHz Range: 75 Hz to 10 kHz
RPM Resolution: Frequency Range (Hz) / 12800 x 60 / Set Pulse Count (P/R)
Measurement Accuracy: +/- 2 x RPM Resolution +/- 1
Measurement Time: 500 ms or Less
Display: Blue-Green LED, 6 Digits
Pulse Count Set Range: 0.5 to 199.5 P/R in 0.5 Steps
Rotational Direction Determination Function: Displays CW or CCW (When Used With FT-0501)
Exponential Averaging: Select: Off, 2, 4, 8, or 16 Times
Analog Output: 0 to 10V / Full Scale
Comparator Output: Yes
Interface: D-SUB (15-Pin Connector)
Dimensions: 144 mm (W) x 72 mm (H) x 180 mm (D)
Weight: Approximately 1.2kg
Pulse Output: 0 to 5V TTL
