Accuracy: ± 0.25 %
Accuracy Note: 0.25% FS linearity and hysteresis combined
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 160 mBar
Pressure, Min: 0 mBar
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 30x Full Scale
Supply Voltage: 24 to 32 Vdc
Mating Connector: MIL-26482-I 10-6S
Compatible Meters: DP41-E,DP25B-E, DP24-E
Electrical Output: 0 to 5 V
Materials, Wetted: 17-4 Stainless Steel
Zero/Balance Error: 0 V ± 10% adj
Burst Pressure Note: 300% of rated pressure
Line/Static Pressure: 150% rated pressure (applied simultaneously to both sides)
Additional Features 1: Twist-Lock Connector
Electrical Connection: MIL-26482-I 10-6P
Electrical Output Note: 0 to 5 Vdc ± 10% adjustable
Process Connection Size: 1/4 in
Process Connection Type: BSPP Female
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -46 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 17 °C
Thermal Effect on Zero error, Max: ± 0.0054% rdg/°C, ± 0.0054% FSO/°C
