Weight: 254 g
Accuracy: ± 0.5 %
Stability: ≤± 0.25%
Vibration: 100 g peak, 11 ms; Vibration Random: 10 g RMS, 20 to 2000 Hz; Vibration Sweep : 50 to 2000 Hz, 5 g peak
Protection: Reverse polarity and mis-wire protected
Accuracy Note: ± 0.5% TP; ± 0.40% BFSL includes non-linearity, hysteresis and non-repeatability, zero offset and span setting errors (add 0.05% for ranges above 5000 psi)
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 0 psi
Response Time: 2 ms
Accuracy Class: > 0.25%
Stability Note: ≤± 0.25% span/year @ ref conditions (21°C/70°F)
Supply Voltage: 12 to 32 Vdc
Position Effect: ± 0.02% typical
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 7, NEMA Type 9
Materials, Wetted: 316 Stainless Steel
Relative Humidity: 0 to 0.95
Supply Power Note: 12 to 32 Vdc Vmin=12V+(0.022Ax loop res)
Enclosure Material: 304 Stainless Steel
Fits Cable Diameter: 9 to 12 mm
Additional Features 1: None
Electrical Connection: 1/2 NPT male Conduit with Cable
Insulation Resistance: 100 MΩ
Electrical Output Note: 4 to 20 mA(2 wire)
Process Connection Note: 1/2 NPT male conduit fitting and 4.6 m (15') cable with flying lead termination
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 125 °C
Process Temperature, Min: -40 °C
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 125 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 85 °C
Compensated Temperature, Min: -20 °C
Thermal Effect on Span error, Max: 2% span
Thermal Effect on Zero error, Max: 2% span
