Accuracy: ± 0.25 %
Cable Length: 10 in
Accuracy Note: 0.25% FS linearity and hysteresis combined
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 10 to 40 Vdc
Sensing Element: 4-active-arm Strain Gauge Bridge
Electrical Output: 4 to 20 mA
Materials, Wetted: 17-4 Stainless Steel, 316 Stainless Steel
Zero/Balance Error: 4 mA (+10%, -2% adj)
Burst Pressure Note: 300% of rated pressure
Sensing Element Note: 4-active-arm bridge with hermetically sealed thick-film strain gages
Additional Features 1: Mine Safety and Health Admin
Electrical Connection: Screw Terminal
Electrical Output Note: 4 to 20 mA ± 10% adj
Process Connection Note: <10,000 psi 1⁄2-14 NPT external and 1⁄4-18 NPT internal 10,000 F250C autoclave 9⁄16-18 thread
Process Connection Size: 1/2 in x 1/4 in
Process Connection Type: NPT Male and Female
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -47 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Thermal Effect on Span error, Max: 0.003% of rdg/°F
Thermal Effect on Zero error, Max: 0.003% of rdg/°F, 0.003% of rdg/°F
