Shock: 50 g, 11 ms half-sine
Weight: 154 g
Accuracy: ± 0.25 %
Bandwidth: DC to 1 kHz
Stability: ± 0.25%
Vibration: ± 20 g
Compliance: RoHS 2
Accuracy Note: ± 0.25% BSL, max (Combined Linearity, Hysteresis and Repeatability) Zero or Span Setting Accuracy: ± 2% FS
Output Signal: Millivolt
Pressure Note: Pressure Overload: -15 to 50 psig and 0 to 1000 psia: 3 times rated pressure or 20 psi whichever is greater, 100 to 10,000 psig: 2 times rated pressure
Pressure Type: Absolute
Pressure, Max: 500 psi
Pressure, Min: 0 psi
Response Time: <1 ms
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 4x Full Scale
Stability Note: 1-Year Stability: <0.25% FS
Supply Voltage: 9 to 30 Vdc
Pressure Cycles: 10 million, minimum
Electrical Output: 100 mV/V
Enclosure Ratings: IP65
Enclosure Material: 316 Stainless Steel
Burst Pressure Note: -15 to 50 psig and 0 to 1000 psia: 4 times rated pressure or 25 psi whichever is greater, 100 to 10,000 psig: 5 times rated pressure
Additional Features 1: None
Electrical Connection: MIL-26482-I 10-6P
Insulation Resistance: 1 MΩ @ 25 Vdc
electrical-connection: MIL-26482-I 10-6P
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Shunt Calibration Value: In vertical direction with fitting down, compound ranges are calibrated for positive pressure output only
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 50 °C
Compensated Temperature, Min: 0 °C
Thermal Effect on Span error, Max: ± 0.03%
Thermal Effect on Zero error, Max: ± 0.03%, ± 0.03%
