Shock: 200 g
Width: 152 mm
Length: 102 mm
Weight: 0.7 kg
Accuracy: ± 1 %
Diameter: 51 mm
Vibration: 10 g from 50 to 2000 Hz
Applications: Air and HVAC, Energy Generation and Distribution, Fluid Measurement and Control, Industrial and Manufacturing, Level Monitoring and Control
Accuracy Note: Accuracy RSS Ranges A, B & C: ± 1.0% Full Scale; Range D: ± 2.0% RSS full scale
Cavity Volume: 0.2 cc
Output Signal: Selectable
Pressure Type: Differential
Pressure, Max: 100 psi
Pressure, Min: 0 psi
Response Time: 1 to 5 sec
Accuracy Class: > 0.25%
Burst Pressure: 40 psi Maximum
Proof Pressure: 2.2x Full Scale
Supply Voltage: 12 to 30 Vdc
Electrical Output: 4 to 20 mA
Enclosure Ratings: NEMA Type 4
Materials, Wetted: 17-4 Stainless Steel
Supply Power Note: 12 to 30 Vdc @ 5 mA (typical)/18 to 28 Vac 40 mA (typical) (reverse polarity protected)
Enclosure Material: Die cast aluminum powder coated
Response Time Note: 1 to 5 seconds, selectable
Burst Pressure Note: 40 x FS
Proof Pressure Note: 2.2X FS
Additional Features 1: Rangable
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Electrical Output Note: 0 to 5 Vdc, 0 to 10 Vdc, 1 to 5 Vdc 3-wire system
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
Compensated Temperature, Max: 54 °C
Compensated Temperature, Min: 0 °C
Thermal Effect on Zero error, Max: 2.0% FS, 2.0% FS
