Height: 2.25 in
Length: 2.3 in
Switch: Single
Weight: 7.8 oz
Cycling: < 20 cycles/min
Materials: Gold-Plated Contacts
Insulation: PVC
Wire Gauge: 20 AWG
Output Note: 1 A Gold-Plated Contacts for TTL or Dry Contacts
Switch Type: SPST
Output Value: 1A @ 115 Vac
Deadband Type: Fixed
Pressure Type: Compound Gauge
Pressure, Max: 200 inH₂O
Pressure, Min: 2.75 inH₂O
Switch Rating: 1A @ 115 Vac
Control Output: SPST Relay
Proof Pressure: Up to 20 psi
Materials, Wetted: 316 Stainless Steel, Aluminum, Buna-N (NBR), Methacrylate Ester
System Pressure, Max: 20 psi
Electrical Connection: Pigtail Leads
Setpoint Repeatability: ± 0.8 inH20
Wiring/Connector Table: Red = N/C, White = N/O, Black = Common
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Decreasing Pressure, Max: -6.8 inHg
Decreasing Pressure, Min: -100 inHg
Increasing Pressure, Max: -5.4 inHg
Increasing Pressure, Min: -100 inHg
Process Temperature Note: -55 to 90°C (-67 to 194°F); a setpoint change of up to 2% of sensor capacity can be anticipated when switch is used either below -25°C (-13°F) or above 50°C (122°F)
Process Temperature, Max: 90 °C
Process Temperature, Min: -55 °C
