Pressure Type: Vacuum
Pressure Range Units: bar
Pressure Range Min: 0
Pressure Range Max: -1
Pressure Port Type: NPT Male
Pressure Port Size: 1/2"
Accuracy Value: ±1%
Accuracy Class: > 0.25%
Dial Size: 100mm
Additional Features: Bottom mounting, Dual Scale
Accuracy: 100 mm ±1% of span (Grade 1A)
Working Pressure: 75% of full scale
Over Range Protection: 130% of full scale
Ambient Temp. Range: -40 to 60°C (-40 to 140°F)
Process Temp. Range: -20 to 80°C (-4 to 176°F)
Degree of Protection: IP65
Element: 316 stainless steel
Window: 100 mm: laminated safety glass
Dial: White Aluminum with black lettering
Pointer: Aluminum alloy, black painted
Case and Bezel Ring: 304 stainless steel
Movement: 304 stainless steel
Pressure Connection: 316 stainless steel, ½ MNPT on 100 mm
Blowout Protection: back mounted rubber disc
See more detail information in the Datasheet
