Weight: 30 g
Display: No
Accuracy: ± 1 %
Impedance: 20 to 60 kΩ
Spot Size: 3 mm
Weight Note: Approx 30 g (1 oz)
Cable Length: 36 in
Laser Output: false
Accuracy Note: 1% under calibration conditions
Field of view: 1:2
Output Detail: Thermocouple Type K
Output Signal: Thermocouple
Response Time: 150 ms
Spot Size Note: 3 mm(0.1") @ zero distance
Emissivity Note: 0.90 Fixed
Emissivity, Max: 0.9
Housing Material: 300 Series Stainless Steel
Cable Length Note: 8 m (36") 30 AWG solid wire with glass braid insulation and tin/copper overbraid
Intrisically Safe: No
Field of View Note: 1:2(distance:spot)
Relative Humidity Note: Non-condensing
Spectral Response, Max: 14 μm
Spectral Response, Min: 6.5 μm
Process Temperature, Max: 50 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
