Weight: 500 g
Statistics: Average, Peak Hold, Valley Hold
Weight Note: 500g (without cable)
Cable Length: 3 m
Current Draw: 100 mA
Field of view: 300:1
Output Signal: Current
Repeatability: ± 0.3% of reading +1°C
Response Time: 5 ms
Sensor Length: 110 mm
Data Interface: USB
Supply Voltage: 24 Vdc
Emissivity Note: 0.100 to 1.000, in 0.001 increments
Emissivity, Max: 1
Emissivity, Min: 0.1
Sensor Diameter: 59.5 mm
Cable Length Note: 3 m (standard, 4-cores), 5 m/10 m
Enclosure Ratings: IP64
Intrisically Safe: No
Supply Power Note: 24 VDC ± 20%
Response Time Note: 5 ms ((95% signal))
Loop Resistance, Max: 500 Ω
Additional Features 1: Simultaneous analog and digital outputs
Relative Humidity Note: 10 to 95%, non-condensing
Relative Humidity, Max: 95%
Relative Humidity, Min: 10%
Spectral Response, Max: 1 μm
Temperature Resolution: 0.1 °C
Process Temperature, Max: 1600 °C
Process Temperature, Min: 600 °C
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 0 °C
