Weight: 600 g
Display: Yes
Isolation: Power supply, *Digital output and Analog output are galvanically isolated * Not applicable for USB 2.0 digital output
Laser Power: None
Cable Length: 3 m
Laser Output: false
Relay Output: 60 Vdc
Accuracy Note: ± 1% of the measured value or 3°C whichever value is greater (The sensor head must be at constant ambient temperature for a minimum of 15 minutes)
Field of view: 15:1
Housing Width: 82.5 mm
Output Detail: 0 to 20mA, 4 to 20mA, 0 to 10V, Thermocouple Type “K” or “J”, Relay Output with hysteresis 60V DC/42V AC RMS,0.4A
Output Signal: Current, Voltage
Repeatability: 0.003
Response Time: 20 ms
Control Output: Relay Output with hysteresis 60V DC/42V AC RMS,0.4A
Data Interface: USB
Housing Height: 33 mm
Housing Length: 112.5 mm
Supply Voltage: 12 to 28 Vdc
Emissivity, Max: 1.2
Emissivity, Min: 0.1
Sighting Option: None
Housing Material: Stainless Steel,Zinc
Electrical Output: 0 to 20 mA, 4 to 20 mA, 0 to 10 Vdc
Enclosure Ratings: IP65
Intrisically Safe: No
Power Consumption: 2.5 W
Relay Output Note: Relay Output with hysteresis 60V DC/42V AC
Supply Power Note: 12V to 28V DC with reverse polarity protection
Photodetector Type: Thermopile
Repeatability Note: 0.3% of reading + 1°C
Response Time Note: 20 msec adjustable up to 10 sec
Relative Humidity, Max: 0.95
Relative Humidity, Min: 10%
Spectral Response, Max: 14 μm
Spectral Response, Min: 8 μm
Temperature Coefficient: ± 0.06%
Process Temperature, Max: 800 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 120 °C
Operating Temperature, Min: 0 °C
Temperature Coefficient Note: ± 0.06 °C/°C (0.06 °F/°F) or ± 0.06 % (whichever is greater)
