Width: 33 mm
Height: 86 mm
Length: 43 mm
Memory: 3,593,358 Readings
Weight: 227 g
Software: Standard Software version 4.2.15.0 or later Secure Software version 4.2.14.0 or later, Windows XP SP3/7/8/10
Approvals: CE
Materials: Aluminum
Resolution: Pressure : 0.05 mbar, Humidity : 0.1% RH, Temperature : 0.1°C, Acceleration : 0.02 g , 0.05 g, 0.2 g
Calibration: Digital calibration through software and automatically recorded within device
Memory Note: 3,593,358 readings (598,893 per channel, all channels in use)
Start Modes: Delayed Start, Immediate Start
Battery life: up to 3 mo
Accuracy Note: Calibration Accuracy : Humidity : ±3 %RH (±2 %RH typical at 25 °C), Pressure : ±1.5 mbar at 25 °C; at 750 mbar, Temperature : ±0.5 °C (+5 °C to +60 °C); Time Accuracy : 10 seconds/month (at 0 °C to 50 °C)
Pressure Type: N/A
Pressure, Max: 1300 mBar
Pressure, Min: 100 mBar
Sampling Rate: 1024 Hz (1024 updates/second)
Time Accuracy: 10 seconds/month
Data Interface: USB
Humidity Range: 0 to 95% RH non-condensing
Data protection: Access by password
Millivolt Range: N/A
Measurement Type: Temperature, Humidity, Pressure, Shock
Enclosure Ratings: IP64
Supply Power Type: Battery
Acceleration Range: ± 15 g , ± 100 g , ± 300 g
Calibration Option: NIST
Frequency Response: >1000 Hz (15 g), >500 Hz (100 g, 300 g)
Sampling Rate Note: 1024 Hz to 5 minutes for shock, selectable in software. Temperature, pressure and humidity sampled approx. every 2 seconds at intervals shorter than 2 seconds. Otherwise, sampled at the reading rate.
Real Time Recording: May be used with PC to monitor and record data in real time at a 1 second sample rate
Calibration Accuracy: Humidity : ±3% RH, Temperature : ±0.5 °C, Pressure : ±1.5 mbar, Accelerometer : ±0.3 g/±2.0 g/±6.0 g
Battery Size and Type: Li-ion
Number of Measurements: N/A
Process Connection Size: 1/4 in
Process Connection Type: N/A
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Measuring Temperature Range, Max: 60 °C
Measuring Temperature Range, Min: -20 °C
