Length: 50.8 mm
Memory: 32,700 Readings
Weight: 85 g
Diameter: 25.4 mm
Mounting: Flush Mount
Software: Windows XP SP3 / Vista / 7 and 8 (32 and 64 - bit)
Approvals: CE
Baud Rate: 125000
Materials: Stainless Steel
Resolution: Pressure : 0.0015 psi
Stop Modes: Adjustable Delay Stop
Calibration: Digital Calibration through Software with Montly Calibration interval
Memory Note: 32,700 readings; software configurable memory wrap
Start Modes: Delayed Start, Immediate Start
Battery life: up to 2 yr
Accuracy Note: Calibration Accuracy : Pressure: ±0.435 psi @ 20 to 140ºC; Time Accuracy : ±1 minute/month at 20ºC; Pressure Repeatability : ±0.5% FSR; ±0.2% typical
Pressure Type: Absolute
Pressure, Max: 72.5 psi
Pressure, Min: 0 psi
Sampling Rate: 1 Hz (1 update/second)
Time Accuracy: ±1 minute/month
Data Interface: USB
Humidity Range: 0 to 100% RH
Millivolt Range: N/A
Measurement Type: Pressure
Supply Power Type: Battery
Frequency Response: Pressure Response Time: 0.1 ms
Sampling Rate Note: 1 second to 1 every 24 hours
Real Time Recording: The device may be used with PC to monitor and record data in real-time
Calibration Accuracy: Pressure: ±0.435 psi
Battery Size and Type: 3.6V Li-ion
Number of Measurements: 1
Pressure Repeatability: ±0.5%
Process Connection Size: N/A
Process Connection Type: N/A
Operating Temperature, Max: 140 °C
Operating Temperature, Min: -20 °C
