Weight: 0.17 kg
Approvals: CE, RoHS, UKCA
Insulation: PVC
Switch Note: SPDT 15 A @ 125 or 250 Vac; 10,000,000 operations median
Switch Type: SPDT NO/NC, Selectable
Probe Length: 4.8125 in
Switch Rating: 15 A @ 125 or 250 Vac
Specific Gravity: 0.6
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: 316 Stainless Steel, EPDM, Noryl
Media Compatibility: Oil, Solvents, Water
Strain Relief Fitting: 0.25 in ± 0.025 in
Operating Pressure, Max: 200 psi
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Male
Operating Temperature Note: LV-1100 Series: 300 psig @ 82°C (180°F), LV-1202: 75 psig @ 93°C (200°F), 100 psig @ 23°C (75°F), LV-1201: 75 psig @ 23°C (75°F), 200 psig @ 10°C (50°F), LV-1203: 75 psig @ 93°C (200°F), 100 psig @ 230°C (75°F)
Operating Temperature, Max: 10 °C
Operating Temperature, Min: 0 °C
Material Construction Option: Plastic
