Width: 6.13 in
Height: 4 in
Length: 12.99 in
Weight: 1.44 lb
Display: LCD
Software: Access web server using any modern web browser such as Chrome, Edge, or Firefox on the same local network; Firmware upgrade from Internet; Export probe data log to CSV files
Approvals: CE, UKCA, ICES-3(B)/NMB-3(B), FCC
Alarm Note: Two contact inputs TTL 0.5 mA; one open collector output 150 mA @ 30 V DC
Input Type: External
Probe Type: Smart Probe
Form factor: Wall Mount
Samples,Max: 75M Samples, Interval 1 Sample / Second, Continue logging up to 10 000 data points for a period of 96 hours
Sensor Type: Thermocouple
Battery life: up to 96 hr
Display Note: LCD 32 mm L x 93.5 mm W
Configuration: Internal Web UI
Logging Modes: Fixed interval
RH Resolution: 0.1%, 12 bit
Certifications: NIST Traceable Calibration
Data Interface: Ethernet, USB
LED Indicators: 100 BASE-T, Network Link and Activity, Internet
Supply Current: 1.5 A
Supply Voltage: 9 to 12 Vdc
Measurement Type: Temperature
Supply Power Note: Back-Up Battery: 9 V DC, alkaline, Power Consumption: 4 W, AC Power Adapter (Included) Nominal Output: 12 V DC @ 1.5 A, Power over Ethernet: IEEE 802.3AF, 44 V - 49 V, Power Consumption under 10 W
Thermocouple Type: J, K, T, E, R, S, B, C, N
Data Interface Note: Ethernet (RJ45): 1x port (Power over Ethernet available on qualifying models) Supported Protocols: TCP, UDP, SNMP, SNTP, ARP, ICMP, DNS, HTTP, and Telnet
Temperature Accuracy: 1 °C, 0.5 °C
Additional Features 1: PoE
Battery Size and Type: Alkaline 9V
Electrical Connection: M12 8 pin Female
Temperature Stability: 0.08°C/°C
Cable Temperature, Max: 125 °C
Cable Temperature, Min: -40 °C
Number of Measurements: 2
Temperature Resolution: 0.1 °C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: 0 °C
Temperature Measurement, Max: 1372 °C
Temperature Measurement, Min: -200 °C
Thermocouple Lead Resistance: 100 Ω max
Battery Operating Temperature: -18 to 55 °C
Thermocouple Cold End Tracking: 0.05°C/°C
AC Adaptor Operating Temperature: 0 to 40 °C
