Accuracy: ± 1 %
Compliance: CE
Calibration: NIST Certificate
Display Type: LCD
Accuracy Note: For units with full range less than 100 SLM ± 1% FS, including linearity over 15 to 25°C (59 to 77°F) and 0.7 to 4.2 kg/cm² (10 to 60 psia). For units ≥ 100 SLM Full Range: ± 1.5% FS, including linearity over 15 to 25°C (59 to 77°F) and 0.7 to 4.2 kg/cm² (10 to 60 psia) from 20 to 100% of range; ± 3% FS from 0 to 20% of range
Control Valve: Solenoid Valve
Output Detail: Linear 0 to 5 Vdc: 1000 V minimum load 4 to 20 mA: 50 to 500 V loop resistance, ± 20 mV max noise
Output Signal: Current, Voltage
Repeatability: ± 0.5%
Response Time: 5 sec
Humidity Range: 0 to 70% RH
Supply Current: Up to 800 mA
Supply Voltage: 12 to 15 Vdc
Turndown Ratio: 40:1
Electrical Output: 4 to 20 mA, 0 to 5 Vdc
Enclosure Ratings: Inst. Level II/Poll. Degree II (IEC 60664)
Materials, Wetted: FKM, Stainless Steel
Pressure Drop, Max: 50 psi
Response Time Note: 5 seconds to within ± 2% of set flow rate over 25 to 100% FS
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Altitude Sensitivity: Horizontal flow path, no shift in calibration up to +20 degree pitch
Pressure Coefficient: 0.01% FS/psi
Leak Rate Under Vacuum: less than 10^⁻⁷ cc He/s
Operating Pressure Note: 35 kg/cm² gage (500 psig); 70 kg/cm2 gage (1000 psig) for ranges up to 100 SLPM. 1.76 kg/cm (25 psig) optimum
Operating Pressure, Max: 1000 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 3/8 in
Process Connection Type: Compression Fitting
Temperature Coefficient: 0.15% FS/°C
Volumetric Flow Rate, Max: 80 SLM
Volumetric Flow Rate, Min: 0.25 SCCM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 5 °C
Material Construction Option: Stainless steel Body
material-construction-option: Stainless steel Body
