Width: 1 in
Height: 6 in
Length: 3.29 in
Weight: 1.25 lb
Accuracy: ± 1 %
Calibration: NIST 5-Point Certificate
Display Type: LCD
Accuracy Note: ± 1% of full scale including linearity
Control Valve: Solenoid Valve NC
Output Detail: Linear 0 to 5 Vdc,1000 Ω min load, 4 to 20 mA,500 Ω loop resistance
Output Signal: Current, Voltage
Repeatability: ± 0.15%
Response Time: 5 sec
Supply Current: 150 mA
Supply Voltage: 24 Vdc
Turndown Ratio: 100:1
supply-voltage: 24 Vdc
Electrical Output: 4 to 20 mA, 0 to 5 Vdc
Materials, Wetted: 17-4 Stainless Steel, 316 Stainless Steel, FKM
Supply Power Note: 24 Vdc @ 150 mA, 115 Vac, 220 Vac with AC adaptor
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Pressure Coefficient: 0.01% FS/psi
Additional Features 1: Power Supply Included
Electrical Connection: Sub-D Male Miniature Connector
Leak Rate Under Vacuum: less than 10^⁻⁶ cc He/s
Required Pressure, Min: 1 inH₂O
Operating Pressure, Max: 500 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: Compression Fitting
Temperature Coefficient: 0.05% FS/°C
Volumetric Flow Rate, Max: 5 SLM
Volumetric Flow Rate, Min: 0.1 SCCM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
