Width: 1.1 in
Height: 3.9 in
Accuracy: ± 0.8 %
Span Shift: 0.02% FS/°C/atm
Calibration: NIST Certificate
Display Type: LCD
Accuracy Note: ± (0.8% of reading + 0.2%FS)
Output Signal: Voltage
Pressure, Min: 5 psi
Repeatability: ± 0.2%
Response Time: 100 ms
Data Interface: RS232
Humidity Range: 0 to 100% RH non-condensing
Supply Current: 750 mA
Supply Voltage: 24 to 30 Vdc
Turndown Ratio: 200:1
Excess Flow Rate: 2.4% FS
Electrical Output: 0 to 5 V
Materials, Wetted: Aluminum, Epoxy, FKM, Glass, Gold, Silicone, Stainless Steel
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Input Control Signal: 0 to 5 Vdc
Additional Features 1: Power Supply Included
Electrical Connection: 8-pin mini DIN
Operating Pressure Note: 145 psig To Use in Volumetric Mode: Near atmosphere, 15 psig recommended maximum. Volumetric flow meters and controllers not certified for accuracy at mass flow rates above the rated flow range of the meter. They are designed for near atmospheric pressure conditions only. The recommended maximum operating pressure is 15 psig
Operating Pressure, Max: 15 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 3000 SLM
Volumetric Flow Rate, Min: 0.0025 SCCM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
