Scale: Digital
Accuracy: ± 2 %, ± 5% with transitional flow
Isolation: Inherently isolated from the piping system
Materials: 316 Stainless Steel, Stainless Steel
Connection: 4 - Pin Connection
Digit Size: 0.70" - Numeric, 0.35" - Alphanumeric
Display Type: LCD
Air Flow, Max: 0 m³/s
Non-Linearity: ± 0.05%
Repeatability: ± 0.5%
Response Time: 1 sec
Valve Included: false
Water Flow, Max: 5 GPM
Water Flow, Min: 0.5 GPM
Number of Digits: 8
Enclosure Ratings: IP52, IP54, NEMA Type 12, NEMA Type 13
Materials, Wetted: Brass, Carbon Steel, Ceramic, FKM, PPS, Silicone, Stainless Steel
Power Consumption: max 25 mA
Circuit Protection: Reverse polarity, Current Limit
Media Compatibility: Water
Temperature Drift Note: 0.05% of span per °C maximum
Operating Pressure, Max: 3500 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Scale Media Calibration: Water
Process Temperature, Max: 116 °C
Process Temperature, Min: -29 °C
