Width: 1.05 in
Height: 4.4 in
Length: 2.4 in
Accuracy: ± 2 %, ± 5% with transitional flow
Span Shift: 0.02%/ATM FS/°C
Calibration: NIST Certificate
Display Type: LCD
Output Signal: Voltage
Response Time: 20 ms
Data Interface: RS232
Supply Current: 30 mA
Supply Voltage: 7 to 30 Vdc
Turndown Ratio: 50:1
supply-voltage: 7 to 30 Vdc
Excess Flow Rate: Approx 28% overage
Electrical Output: 0 to 5 V
Materials, Wetted: 302 Stainless Steel, 303 Stainless Steel, 316 Stainless Steel, FKM, Polythermide, Silicone
Pressure Drop, Min: 0.4 psi
Media Compatibility: Alcohol, Liquids, Oil, Water
Electrical Connection: 8-pin mini DIN
Operating Pressure, Max: 200 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 5 l/min
Volumetric Flow Rate, Min: 0.001 cm³/min
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 10 °C
