Shock: MIL-STD-202G Method 213 B
Window: Polycarbonate
Backlight: true
Bar Graph: 20 segment vertical
Vibration: MIL-STD-202G Method 201A
View Angle: 12 o’clock
Battery life: 2000 hr
Display Type: 5 Digit LCD
Accuracy Note: 0.25% FS terminal point (0.5% full scale terminal point for ranges 15 psi, 30 Vac, 30V15 and 30V30)
Pressure Type: Gauge
Pressure, Max: 2000 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Proof Pressure: 150% Full Scale
Pressure Cycles: 10 million
Protective Boot: Standard
Keypad Functions: 3 Key with Multi Press Functionality On/Off: Power symbol and enter Zero: Zero, tare, and scroll up arrow Menu: access, backlight, down arrow Engineering Units: psi, bar, inHg, cmHg, mmHg, kPa, mPa, kg/cm2, ftH2O, custom units, except on compound gauge ranges Auto-Off: Programmable for 1, 5 or 20 minutes or none for on/off. Display Update: Adjustable for 1 sec, 500 msec or 250 msec.
Number of Digits: 5
Display Indicator: 4-segment battery life indicator plus dedicated icons for gauge timer, backlight timer, tare, min and max
Display Type Note: Type: LCD Display Digits: Five (5) Character Height: 3˝ .60˝, 41 ⁄2˝ .88˝ Backlite: Optional Bar Graph: Yes Battery Life: 3˝ >1000 hrs., 41 ⁄2˝ >3600 hrs. Agency Approvals: CE, FM* (Intrinsically Safe Class1, Div 1), CSA and CENELEC *FM is not available with the following: 41 ⁄2˝ polypropylene case, SPDT switch option(s) (XU1, U2) or Backlite (XBL) option).
Enclosure Ratings: IP67, NEMA Type 4X
Materials, Wetted: Stainless Steel
Pressure Accuracy: ± 0.25 %
Supply Power Type: Battery
Enclosure Material: Polycarbonate
Sample/Display Rate: 1 Hz
Display Segment Height: 12.2 mm (0.48") upper line; 6.1 mm (0.24") lower line
Process Connection Note: 1 ⁄4 NPT male, lower position up to 10,000 psi >10,000 psi: ⁹⁄₁₆-18 UNF Female AMINCO
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: -20 °C
Process Temperature, Min: 60 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
