Width: 63 mm
Height: 101 mm
Length: 44 mm
Weight: 0.16 kg
Stability: (1 Year): ± 0.25% FS typical
Auto-Shutoff: 1 hour
Battery life: 100 hr
Accuracy Note: ± 0.5% BFSL (includes non-linearity, hysteresis, repeatability)
Pressure Type: Gauge
Pressure, Max: 1000 psi
Pressure, Min: -14 psi
Accuracy Class: > 0.25%
Burst Pressure: 4x Full Scale
Proof Pressure: 2x Full Scale
Pressure Cycles: >100 million cycles
Number of Digits: 3.5
Materials, Wetted: Stainless Steel
Pressure Accuracy: ± 0.5 %
Supply Power Type: Battery
Sample/Display Rate: 3 samples per second
Thermal Span Effect: <± 1.5% FS
Thermal Zero Effect: <± 1.5% FS
Battery Size and Type: Alkaline 9V
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 55 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 65 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: 0 °C
