Width: 35 mm
Height: 78 mm
Length: 64 mm
Weight: 180 g
Accuracy: ± 0.5 %
Burn-Out: At the end of scale
DC Pulse: Isolation: Output NOT isolated as regard the very low voltage parts; Logic State: 1: 12V ± 20% @ 1 mA, 10V ± 20%; @ 20 mA ; Logic State 0: <0.5V
Mounting: Flush in panel
Isolation: Reinforced isolation between low voltage (input and output relay) and frontal parts; reinforced isolation between low voltage and very low voltage parts (inputs, static outputs)
Input Type: Thermocouple
Resolution: 0.1°C
Form factor: 1/8 DIN
Device Class: Class II
Display Size: 47 mm (1.9 in)
Display Type: 3 Digit LED
Accuracy Note: ± (0.5% span ± 1 digit @25 °C
Output Detail: DC pulse/Relay;Output Action : Direct/reverse, programmable Contact : SPDT Contact Load : Out 1 - 8 A/250 Vac on resistive load - 3 A/250V Relay Electric Life : 100,000 operations
Output Signal: DC Pulse
Sampling Rate: 1 Hz (1 update/second)
Control Output: DC pulse, SPDT Relay
Supply Voltage: 100 to 240 Vac/Vdc
supply-voltage: 100 to 240 Vac/Vdc
Measuring Range: J: -40 to 999°C (-40 to 999°F) K: -40 to 999°C (-40 to 999°F)
Measurement Type: Temperature
Number of Inputs: 1
Display Type Note: 3-digit single display, red, 12 mm (0.47")
Enclosure Ratings: IP65
Relative Humidity: < 95 RH% without condensation
Supply Power Type: AC
Additional Features 1: °C or °F programmable
Display Updating Time: 1 s
Electrical Connection: Screw Terminal
Nominal Pulse Voltage: 2.5 KV
Thermistor Resistance: None
Enclosure Ratings Note: Front Protection: IP 65 (with gasket) according to EN60070-1 for indoor use Screw Terminal: IP20
Category of Overvoltage: II
Storage Temperature, Max: 60 °C
Storage Temperature, Min: -25 °C
Number of Control Outputs: 2
Cold Junction Compensation: Automatic compensation 0 to 50°C; Accuracy: 0.1°C/°C @ 25°C after a warm-up (instrument switch-on) of 20 minutes
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
