Reset: 0 to 50 repeats/min
Scale: Digital
Width: 192 mm
Height: 160 mm
Length: 103 mm
Offset: 0 to 10 (voltage), 0 to 20 (current)
Weight: 1.4 kg
Accuracy: ± 1 °C (± 1.8 °F)
RTD Type: 100 Ω Pt Sensor
Scan Rate: 2 channels per second
Input Type: RTD
Resolution: 1°C
Form factor: 1/8 DIN
Current, Max: 4 to 20 mA, 0 to 10 Vdc
Display Type: 7 Digit LED
Accuracy Note: ± 1°C ± 1 count
Output Detail: 5 Volts drive @ 50 mA per zone
Output Signal: Voltage
Sampling Rate: 0 to 500 Hz (updates/second)
A/D Conversion: 20,000 count A/D converter
Control Output: None
Supply Voltage: 100 to 240 Vac
Conversion Rate: 7/s
Input Type Note: J, K, T, E, R, S, B, thermistor (2252 Ω @ 25°C), Pt100 RTD 4 to 20 mA loop current Voltage—0 to 5 Vdc, 0 to 10 Vdc Millivolt—0 to 100 mV
Measuring Range: 470 to 1800°C
On/Off Deadband: 0 to FS
Measurement Type: Temperature
Number of Inputs: 7
Decimal Selection: 0,001, 0,01, 0,1, None
Display Type Note: Red 7-segment, 7 Digit LED display, 20 mm (0.8") high Display Test: 8.8.8.8.8.8.8 on power-up
Enclosure Ratings: IP65
Power Consumption: 6 W
Proportional Band: 0 to 100% of span
Supply Power Note: 120 Vac—60 Hz (standard) 220 Vac—50/60 Hz (optional) 15 Vdc @ 900 mA (optional)
Supply Power Type: AC
Thermocouple Type: None
Enclosure Material: Polycarbonate
Channel Display Time: Programmable from 1 to 999 seconds
Additional Features 1: Wall Mounted
Number of Control Outputs: 1
Cold Junction Compensation: Error: ± 0.5°C @10 to 45°C
Open Thermocouple Indication: "HELP" displayed
